1993 Chevrolet C/K Truck - Repair Manuals Blog

In 1993, Chevrolet produced 3500 pickup trucks in C or K versions, Cheyennes, and Silverados, with regular-cab, crew-cab, and extended-cab configurations to meet customer needs. The 3500 came standard with a gasoline engine, although another gas engine and a selection of diesel engines were also available that year.

Overview of the Chevrolet C/K Truck

There are seven trim levels available in the 1993 CHEVROLET C/K TRUCK:

Silverado
Extended Cab
Crew Cab
Base
Cheyenne Extended Cab
Cheyenne Crew Cab
Cheyenne

Performance and Fuel Economy

At 4,000 engine revolutions per minute, the standard 5.7-liter V8 gasoline engine developed 190 power and 300 foot-pounds of torque at 2,400 rpm. The alternative gasoline option was a 7.4-liter V8 with 230 horsepower at 3,600 rpm and 385 foot-pounds of torque at 1,600 rpm. The 6.2-liter diesel engine developed 150 horsepower at 3,500 rpm and 280 foot-pounds of torque at 2,000 rpm. With 3,400 revolutions per minute, the turbo-diesel produced 190 horsepower and 380 foot-pounds of torque with 1,700 revolutions per minute. In contrast, the 6.6-liter turbo diesel produced the same speed and performance as the 6.5-liter turbo diesel. The fuel economy is not great, but given it is a 454 with 4.10 gears, 14 mpg is not awful. You might acquire a 1 ton with a more robust economy, but this one is paid for.

Engine, Transmission, and Dimensions

The standard engine in 1993 Chevrolet C/K Truck was a 5.7-liter V8, which was available on both the K3500 and C3500 versions. (A V8 engine has eight cylinders placed at an angle in two banks.) Other gases and diesel engines were also available in 1993. The 7.4-liter V8 gasoline engine was available in both the Chevy K3500 and C3500 grades. In 1993, a diesel engine with a displacement of 6.2 liters, a turbo engine with a capacity of 6.6 liters, and a turbo engine with a displacement of 6.5 liters were available as options. The baseline engine had dimensions of 4 inches by 3.48 inches and a stroke of 3.48 inches. It used electronic fuel injection and had a fuel tank capacity of 34 gallons.

The 1993 trucks were available with either rear-wheel or four-wheel drive. The K3500 vehicles were four-wheel-drive, while the C3500 versions were rear-wheel-drive. The base gearbox was a five-speed manual with overdrive, while a four-speed automatic with overdrive was available.

Many Options to Choose From

Regular-cab models were 212 inches long, 94.2 inches wide, and 75.5 inches tall. The extended-cab trimmings measured 237 inches in length, 92.4 inches in width, and 75.6 inches in height. Legroom was 41.7 inches, shoulder room was 66 inches, hip space was 60.5 inches, and headroom was 40 inches for these two models. A total of three persons could be accommodated in the extended-cab and regular-cab versions, which had a towing capacity of 10,000 pounds and payload capacities ranging from 3,910 to 4,019 pounds. The crew-cab models accommodated six passengers and had four doors. The cab of the K3500 was larger than that of the C3500.

The front legroom was 41.7 inches, shoulder space was 66 inches, hip room was 60.5 inches, and headspace was 40 inches. The minimum measures for the back seats were 32.4 inches of legroom, 65.4 inches of shoulder space, 59.6 inches of hip room, and 39.9 inches of headroom. The crew cabs seat six people and had a towing capability of 9,000 to 9,500 pounds, with a cargo capacity of 3,843 to 3,566 pounds.

Specification

Height: 75.5 in
Length: 212 in
Width: 94.2 in
Curb weight: 4670 pounds
Passenger volume: N/A
Trunk volume: N/A

Engine type: 5.7-liter V8

Vehicle type: 1-ton pickup truck

Fuel Capacity / Gas Tank Size: 34 gallons

1993 CHEVROLET C/K TRUCK Factory Service Manual

The 1993 Chevrolet C/K Service Manual is in-depth and cover every aspect of your vehicle. Some of the service manuals cover the following topics, which are mentioned below:

Exterior
Dimensions
Interior
Maintenance Strategy
Fuel System
Steering
Suspension
Brake System
Wheels and Tires
Exterior Lights
Climate Control
Sound System
Doors
Engine
Chassis
Body
Index

These repair manuals purpose is to ensure that the owner completes the job properly while maintaining the vehicle’s automotive maintenance or replacements up to date.

1993 CHEVROLET C/K TRUCK — Owner’s Manual

The Chevrolet C/K Truck owner’s manual’s content addressed all of the vehicle’s operations, which included the following items:

Introduction
Climate Controls
Lights
Driver Controls
Locks and Security
Seating and Safety Restraints
Driving
Cleaning
Maintenance and Specifications
Engine compartment
Engine oil
Battery
Fuel information
Accessories
Service Information and Specifications
Maintenance Information and Specifications

Even though this explains the most significant phases, the Chevrolet Owners Manual provides a variety of different operating suggestions for the owner’s convenience and pleasure.
