CASE CX350D EXCAVATOR - Repair Manuals Blog

To put that into perspective, the Case CX350D excavator weighs in at over 82,000 pounds and has a digging force of over 56,000 pounds! (249 kN). According to the manufacturer, new technology and increased cab comfort have been included in the vehicle. Improved speed, control, and fuel efficiency are achieved thanks to the CASE Intelligent Hydraulics System, stronger components, and a powerful Tier 4 Final solution. Exceptional cab comfort is maintained. In addition, the industry-standard ProCare protection is included, allowing owners to focus on their core business while CASE handles the rest.

Performance and Fuel Economy

With a Tier 4 Final solution that includes SCR technology and a DOC, the Case CX350D Excavator meets emission regulations (Diesel Oxidation Catalyst). A Diesel Particulate Filter (DPF) is not required for this technology; therefore, there are no expensive DPF replacement costs, no regeneration downtimes, or temperature spikes related to regeneration. Combustion that is easier on the operator’s hands results in up to 8% more efficiency than the already superb C Series, without sacrificing power or performance. When refueling, add DEF to the tank (Diesel Exhaust Fluid).

Efficiency

The Case CX350D Excavator has lower running costs and its design boosts profitability while decreasing operational expenditures. The CASE Intelligent Hydraulics System (CIHS) actively analyses and adjusts power output during the whole work cycle, which is the basis of its productivity and offers three power modes. Operators benefit from increased efficiency and improved feel and finesse, enabling them to retain pinpoint accuracy down to the inch while maintaining strength throughout the dig and lift cycles.

Power

Faster cycle times and more power are the consequence of a stronger undercarriage, arm, and boom, as well as an electrically controlled pump and bigger control valves. The D Series excavator also has a more robust substructure, arm, and boom, which increases the machine’s longevity and power. Additional features include enhanced control while craning or putting with the Free Swing function and five preprogrammed attachment settings to save time.

Cab Advantages

The cab size is among the best in its class, and it comes standard with a large color display with cameras for both the rearview and side views. To reduce pressure points, the viscous-mounted cab’s standard heated air-ride seat slides tilts back 65 degrees and adjusts to provide enough entry and foot room. The cab is completely pressurized. The horn and radio mute are readily accessible through the joysticks, thanks to the novel armrest design changes independently of the controls. Additional standard features include a Bluetooth radio and an intelligent temperature control system. In addition to LED illumination, the CASE Max View option includes a second-side camera that provides an aerial view of the machine in a 270-degree radius around the machine.

Ease of Maintenance

It’s easy for owners to prolong life, enhance performance, and boost the uptime of their investment, thanks to a variety of serviceability features. The addition of oil sample ports is a standard feature, allowing for quick contamination checks. Many key components are accessible from the ground, and routine servicing areas are grouped together to save time. The coolers have debris screens that can be removed for easy cleaning. The ProCare protection plan also includes a three-year/2,000-hour scheduled maintenance package.

Specification

Height: 11.4 ft
Operating weight: 82483.8 lbs

Engine type: Isuzu 6 HK1X

CASE CX350D EXCAVATOR Factory Service Manual

The CASE CX350D EXCAVATOR service manual is extensive, covering every vehicle operation and maintenance element. A service manual is available for every CASE CX350D EXCAVATOR:

Maintenance
General
Service
Engine
Electrical
Power Transmission
Information System
Cab
Brakes
Steering
Interior
Hydraulic System

CASE CX350D EXCAVATOR repair manuals are for technicians and dealerships to regularly maintain and repair vehicles. The owner uses these service instructions to verify that any maintenance or repairs are done properly and exactly on every occasion.

CASE CX350D EXCAVATOR — Owner’s Manual

The owner’s manual for a CASE CX350D EXCAVATOR contains all important information on the vehicle’s operation and maintenance.

Safety and Security
Operation of each component
Driving
Interior Features
Maintenance and care
Vehicle specifications

The Case Operators Manual, written just for owners, will explain when and how to use their vehicle’s numerous features and functions in detail.
