If you’ve been looking for a lightweight all-arounder but are concerned that smaller tractors lack the features of their bigger stablemates, the Case IH Tractor QUANTUM 95C is the one for you! Its high-octane performance blends the best of compact utility tractor construction with advanced technological features you’ll recognize from larger machines and have come to expect from Case IH in the past.

The QUANTUM 95C takes care of your tasks so that you may spend the whole day working in the field. Vineyards, orchards, and gardens are all excellent locations for putting this versatile utility tractor to use in farming. In addition to a huge choice of factory options ranging from front linkage and power take-off to turf, commercial, and agricultural tires. Other options included high-performance anti-pollen filtration and chemical-absorbing carbon filters. The filters are fitted and tailored at the manufacturing facility to match particular customer needs.

Performance and Fuel Economy

Because of the improved hitch design, heavyweights may be lifted quickly and efficiently with little effort. Whether you chose mechanical or electrical control for the 3-point attachment, all draught sensing was accomplished via the lower links. The result is extremely consistent performance and reliability. It is equipped with two separate hydraulic systems, one for steering and operating a hitch and remote valves on Case IH Quantum 95C. The rear hitch and remotes are powered by a 48l/min pump that responds quickly and has a lift capacity of 2900kg. A higher flow rate pump with a flow rate of 62 liters per minute is available for more demanding applications.

A combination of machines that requires up to six separate double-acting functions may be operated with as few as four double-acting remote valves and the capacity to electronically divert flow via two double-acting valves. Two valves may be set as mid-mounted to make it easier to utilize front-mounted tools to operate them. Thanks to its number-coded design, each connection is equipped with a push/pull connector that can be used with a single hand.

Specifications

Height: 6.3 ft
Length: 364 cm
Width: 7.8 ft
Operating weight: 6768 lbs

Engine type: Turbocharged, intercooler

Vehicle type: Utility tractor

Fuel Capacity / Gas Tank Size: 23.2 gal

CASE IH TRACTORS QUANTUM 95C Service Manual

The extensive service manuals thoroughly cover the CASE IH QUANTUM 95C Tractor components. A CASE IH TRACTORS QUANTUM 95C Service Manual is needed for all repair projects and covers:

Introduction
Engine
Fuel system
Electrical system
Transmission
Axles
Brake system
Power take-off system
Steering system

Technicians and dealerships should utilize CASE IH TRACTOR 95C repair manuals. Every tractor owner should have a service manual on hand while maintaining or repairing his tractor.

Design, Functionality, and Quality

Easy access, a comfortable seat, excellent visibility, a modified fender, and repositioned hydraulic remote levers save fatigue and allow drivers to work confidently. Quantum tractors, available with air conditioning and active carbon filters for enhanced operator protection, provide unsurpassed comfort in the harshest settings.

Because of the low cab height and the possibility of a folding safety frame, work may be carried out under polytunnels and protective nets without interruption. A new folding beacon for cab models will allow the tractor to instantly reduce its profile and pass beneath trees and branches. The remote valve system is adaptable, allowing you to take on any work that requires sophisticated equipment and precise control. Three double-acting remote valves are provided, with the possibility of adding an electro-hydraulic diverter function to offer an additional two valves. The standard outlets are at the back. However, mid-mount couplers may power front or mid-mounted implements.

The Quantum comes standard with a high-spec cab with lots of headroom. While the Case IH QUANTUM 95C is small and narrow on the exterior, there is plenty of space inside. An ergonomic control arrangement, as well as a fully adjustable seat and steering wheel, ensure that your body and mind are never stressed.

With thin cab pillars and rearview mirrors, visibility to operating equipment or trailing sprayers is never a problem. The instrument cluster also contains a performance monitor and an electronic tachometer. Furthermore, there is a mix of analog and digital displays to provide a clear picture of the tractor’s state. Tractor controls are ergonomically positioned, and current features like auto 4WD adapt larger Case IH tractors to make things easier for you.

CASE IH TRACTORS QUANTUM 95C — Owner’s Manual

When you buy a CASE IH tractor QUANTUM 95C, you are given a Case Tractor Manual that includes detailed instructions on undertaking routine maintenance and repairs. It is possible to execute all of the vehicle’s functions by following the instructions in the owner’s manual.

Safety
Maintenance
Chassis
Engine
Drive and Transmission
Electrical
Wiring

Although there are additional operational ideas in the CASE IH QUANTUM 95C owner’s manual to help the driver operate the vehicle more easily, these are the most crucial to be aware of.

CASE IH TRACTORS QUANTUM 95C Price

The CASE IH QUANTUM 95C is out for sale at $43,874.
